Differentiating 2, 4-D and
Dicamba Injury on Soybeans

 Man inspecting the crops

Authors

Marcelo Zimmer, Weed Science Program Specialist

Cade Hayden, Weed Science Research Assistant

Fred Whitford, Clinical Engagement Professor

Bryan Young, Professor of Weed Science

Bill Johnson, Professor of Weed Science





Differentiating 2,4-D and Dicamba Injury on Soybeans

Adoption of dicamba-resistant soybeans (aka Xtend soybeans) by Indiana farmers is expected to reach 4.5  million acres in 2019. The approval of Xtend soybeans allowed farmers to spray dicamba herbicides postemergence for management of glyphosate-resistant weeds such as horseweed, giant ragweed,  waterhemp, and Palmer amaranth. However, the use of this technology resulted in an increased number of herbicide off-target movement complaints across the Midwest from farmers growing non-dicamba tolerant crops. Most of the complaints involved dicamba injury on glyphosate- (Roundup Ready) and glufosinate-(Liberty Link) resistant soybeans, but also affected horticultural food crops and ornamentals. The approval of Enlist E3 soybean imports by China and the Philippines earlier this year has allowed for full commercialization in the U.S. and provided farmers with another auxin herbicide (2,4-D choline) in their soybean weed management programs. In 2019, acreage planted with Enlist E3 soybeans is expected to be low due to limited seed supply; however, full market launch and increased adoption is expected for  2020. Both 2,4-D and dicamba herbicides can move off-target due to primary and secondary drift as well as tank contamination. With dicamba and 2,4-D being auxin herbicides, their symptoms on susceptible soybeans may appear similar at first glance. Differentiating between 2,4-D and dicamba symptomology will become increasingly important for farmers and ag professionals as they evaluate complaints of off-target movement of these two herbicides.

Let’s first look at how the symptoms of 2,4-D and dicamba are similar. At the field application rate, both dicamba and 2,4-D will cause injury symptoms such as leaf droop and stem twisting, also known as  epinasty (Figure 1A). These symptoms will develop quickly after exposure to 2,4-D (within 1 to 2 hours);  however, it may take several hours for these symptoms to develop after exposure to dicamba. There are  only two practical ways to separate 2,4-D and dicamba at high levels of exposure on soybeans. The first way is by checking records of what was applied. The second way is to look for a gradient of herbicide injury with  progressively less injury moving away from the application source.

It’s at lower levels of exposure, often associated with drift, that dicamba and 2,4-D symptoms can be  distinguished (Table 1). Symptoms that are characteristic of low levels of exposure to 2,4-D during vegetative growth stages include: 1) Stem twisting and leaf droop (Figures 1A and 1E); 2) Leaf strapping (Figures 1B,  1C, and 1D); and 3) Callous tissue formation on the soybean stem (Figure 2). Soybean plants will continue  to grow even after fairly high doses of exposure to 2,4-D. In contrast to 2,4-D, stem twisting and leaf droop may not occur at lower levels of dicamba exposure. Injury symptoms that are characteristic of low  levels of dicamba exposure during vegetative growth stages include: 1) leaf cupping (Figure 3), which may  persist for several weeks after exposure; 2) Increased number of nodes, which according to research articles does not translate to yield increases; and 3) Height reduction and death of apical meristem (Figure 4), which typically occur only at higher doses of exposure (equal to or greater than 1% and 10% of field rate,  respectively). The dicamba injury symptoms listed above may take one to three weeks to develop,  depending on dose of exposure and environmental conditions. Although it is not the objective of this article to
discuss potential yield reduction from off-target movement of these herbicides, it is important to understand that soybeans are more sensitive to dicamba than 2,4-D. It requires higher doses of 2,4-D to cause the same levels of injury caused by off-target movement of dicamba. Differences in soybean injury levels and yield reduction in response to 2,4-D and dicamba exposure from a multi-state study are described in Table 2.  Keep in mind that the level of injury and yield reduction in response to these herbicides will vary depending on time of exposure and the environmental conditions after exposure. Therefore, it is difficult to accurately predict soybean yield reduction from visual injury ratings. In conclusion, differentiating 2,4-D and dicamba symptomology is challenging, however, subtle differences do exist. These differences are key for accurate herbicide injury diagnostics.

2,4-D INJURY ON SOYBEANS

Figure 1. Soybean injury in response to 2,4-D (10% of Enlist OneTM field rate). Leaf strapping and stem twisting are characteristic symptoms of exposure to 2,4-D. Notice that strapped soybean leaves show parallel veins.



Stem twisting & leaf droop
Leaf strapping
Leaf strapping
Leaf strapping
Stem twisting

Figure 2. Soybean injury in response to 2,4-D (10% of Enlist OneTM field rate) three weeks after treatment. Callous tissue formation on soybean stems can be observed about a week after exposure, depending on dose and environmental conditions.



Nontreated soybean stem
Callous tissue formation and Stem twisting
Nontreated and 2,4-D treated

Dicamba Injury on Soybeans

Figure 3. Soybean injury in response to dicamba (0.2% of XtendiMax® field rate) 14 days after treatment. Symptoms can persist for several weeks after exposure as these plants continue to set new growth. Notice that the cupped soybean leaves have a whitish to yellow leaf tip, which is another distinguishing feature of dicamba exposure.



The cupped soybean leaves have a whitish to yellow leaf tip, which is another distinguishing feature of dicamba exposure.
The cupped soybean leaves have a whitish to yellow leaf tip, which is another distinguishing feature of dicamba exposure.

Figure 4. Soybean height reduction at 1% of XtendiMax® field rate (left) and apical meristem death at 10% of XtendiMax® field rate (right) in response to dicamba 14 days after treatment. Notice that soybean plants may show a darker green color and more axillary nodes in comparison to nontreated plants.



Nontreated and Dicamba treated (1% of field rate)
Dicamba treated (10% of field rate)

Soybean Sensitivity to 2,4-D and Dicamba

Table 1. Differences in symptomology between off-target movement of 2,4-D and dicamba during vegetative growth.
Symptom Dicamba 2 ,4-D
Stem twisting
and leaf droop		 Requires high levels of exposure associated with tank contamination
or direct application.		 Low and high doses.
Leaf cupping Yes. Cupping will occur at very low doses (Figure 3 - Notice whitish/yellowish
edges of cupped leaves).		 No
Leaf strapping Not typical Yes (Figure 1B, 1C, and 1D – Notice
parallel veins of strapped leaves).
Stem callous tissue formation No Yes (Figure 2).
Height reduction Yes (Figure 4). to or greater than 1% of field rate. Requires high levels of exposure associated with tank contamination
or direct application.
Apical meristem death Yes (Figure 4). Requires dose equal to or greater than 10% of field rate. Apical meristem continues to grow even at fairly high levels of exposure.
Increased number of nodes  Yes. Soybean plants may produce more axillary branches as a result of apical
meristem death. No yield increase has
been documented in research experiments.		 No



 Table 2. Soybean injury 14 days after treatment and yield reduction in response to 2,4-D and dicamba exposure at V2 and R1 growth stages.1
Herbicide Rate (%) Visual Injury (%) Yield (Bu/acre)
Nontreated — 0 0 56 56
Dicamba2 10 76 71 33 14
1 49 31 50 42
0.1 32 22 53 49
0.01 12 9 54 51
2,4-D3 50 83 74 21 22
5 18 18 49 46
0.5 6 2 56 56
0.05 4 1 57 55



































































Table 2 illustrates the differences in soybean sensitivity to 2,4-D and dicamba. Notice that it takes a higher  rate of 2,4-D to cause the same level of injury and yield reduction caused by dicamba exposure. Timing and dose of exposure, as well as environmental conditions following exposure, will influence the potential yield loss from off-target herbicide movement.

1 Data pooled across 9 site-years in a multi-state study funded by the United Soybean Board (USB).
2 Dicamba rate as a percentage of the field labeled rate of XtendiMax® (22 oz/A).
3 Rate of 2,4-D as a percentage of the field labeled rate of Enlist OneTM (32 oz/A).

soybean plant

References

Hayden, NC; Young, JM; Johnson, W; Hager, A; Conley, S; Bradley, K; Steckel, L; Reynolds, D; Norsworthy, J; Kruger, GR; Young, BG (2017). Simulated Tank Contamination with 2,4-D and Dicamba on Dicamba- and Glyphosate-Resistant Soybean Varieties. Page 91 in Proceedings of the North Central Weed Science Society. St. Louis, MO: North Central Weed Science Society.

Johnson, W (2019). Diagnosing Soybean Injury Caused by Dicamba. Webinar available at https://www.plantmanagementnetwork.org/edcenter/seminars/soybean/Dicamba

Robinson, A; Simpson, D; and Johnson, W (2013). Response of Glyphosate-Tolerant Soybean Yield Components to Dicamba Exposure. Weed Science, 61(4), 526-536.
